SVAC1E ECONOMY VACUUM OVEN, 0.6 CUFT, 115V, NON CE

Get a Quotation

SHEL LAB vacuum ovens provide exceptional capabilities for fast and gentle drying of heat-sensitive materials. They prevent residue accumulation on products and allow safe drying of materials at lower temperatures than typically required when using convection ovens.

These units feature a radiant heating system that optimizes chamber space and provides excellent heat transfer and temperature uniformity. All SHEL LAB vacuum ovens are built with stainless steel chambers that are easy to clean and have exceptional durability.

The doors on these units have positive latch handles with spring-loaded glass to facilitate a good vacuum seal without hinge binds that shorten the gasket life. The tempered glass viewing window allows for safe, continuous monitoring of samples. A selection of gaskets (for specific applications) and a small benchtop footprint increase the versatility of these ovens.

The SHEL LAB economy series of vacuum ovens are outstanding in any application.

Features include:

Analog Temperature Control
Stainless-Steel Interior
Built-in Overtemperature Protection
24 Month Limited Warranty

Specs Brochures/Manuals

Model

SVAC1E

Part ID

SVAC1E

Exterior Dimensions (W × D × H)

15.5 × 19 × 22.5
(394 mm × 483 mm × 572 mm)

Interior Dimensions (W × D × H)

9 × 12 × 9
(228 mm × 304 mm × 228 mm)

Volume

0.56 cu.ft. (15.9 L)

Shelf Dimensions (W × D)

8.5 × 11.0 (215 mm × 279 mm)

Unit Weight

59.4 lbs (27 kg)

Interior Metal

300 SST

Exterior Metal

Painted Cold Roll Steel

Operating Temperature Range

Amb +15C - 210C

Temperature Uniformity - Midrange

9.0 °C

Temperature Stability - Midrange

0.5 °C

Controller Type

Analog

Power Voltage , Frequency and Current

110-120 VAC, 50/60 Hz, 5.0 Amps

SVAC1E 110/120V Manual

SVAC1E 220/240V Manual

SVAC1E Brochure
