SHEL LAB vacuum ovens provide exceptional capabilities for fast and gentle drying of heat-sensitive materials. They prevent residue accumulation on products and allow safe drying of materials at lower temperatures than typically required when using convection ovens.
These units feature a radiant heating system that optimizes chamber space and provides excellent heat transfer and temperature uniformity. All SHEL LAB vacuum ovens are built with stainless steel chambers that are easy to clean and have exceptional durability.
The doors on these units have positive latch handles with spring-loaded glass to facilitate a good vacuum seal without hinge binds that shorten the gasket life. The tempered glass viewing window allows for safe, continuous monitoring of samples. A selection of gaskets (for specific applications) and a small benchtop footprint increase the versatility of these ovens.
The SHEL LAB economy series of vacuum ovens are outstanding in any application.
Features include:
  • Analog Temperature Control
  • Stainless-Steel Interior
  • Built-in Overtemperature Protection
  • 24 Month Limited Warranty



Part ID


Exterior Dimensions (W × D × H)

18.5 × 27.8 × 25.3
(470 mm × 705 mm × 641 mm)

Interior Dimensions (W × D × H)

12 × 20 × 12
(304 mm × 508 mm × 304 mm)


1.67 cu.ft. (47.2 L)

Shelf Dimensions (W × D)

11.3 × 19.0 (287 mm × 482 mm)

Unit Weight

108 lbs (49 kg)

Interior Metal

300 SST

Exterior Metal

Painted Cold Roll Steel

Operating Temperature Range

Amb +15C - 210C

Temperature Uniformity - Midrange

9.0 °C

Temperature Stability - Midrange

0.5 °C

Controller Type


Power Voltage , Frequency and Current

110-120 VAC, 50/60 Hz, 10.0 Amps

Max HVAC Load

3480 BTUs/hr

SVAC2E 110/120V Manual

SVAC2E 220/240V Manual

SVAC2E Brochure
